📋 Detailed Specifications

🎥 Camera

•
  Image Sensor: 3K CMOS

•
  Max Resolution: 2960 × 1665 (3K)

•
  Minimum Illumination:


  Color: 0.01 Lux


  B/W: 0 Lux (with IR)



•
  Shutter Speed:


  PAL: 1/25 s – 1/50,000 s


  NTSC: 1/30 s – 1/50,000 s



•
  Day/Night: ICR (auto switching)

•
  Signal System: PAL / NTSC


🔍 Lens

•
  Type: Fixed lens

•
  Options: 2.8 mm / 3.6 mm

•
  Field of View (FOV):


  2.8 mm: ~105° (H)


  3.6 mm: ~92° (H)



•
  Lens Mount: M12


🌙 Illumination (Night Vision)

•
  IR Distance: Up to 25 m

•
  White Light Distance: Up to 20 m

•
  Light Type: Smart Hybrid (IR + White Light)


🎞️ Video & Image

•
  Frame Rates:


  TVI: 3K @ 20fps


  4MP @ 25/30fps


  1080p @ 25/30fps



•
  Video Output: TVI / AHD / CVI / CVBS (switchable)

•
  WDR: Digital WDR

•
  Image Features:


  Brightness / Sharpness adjustment


  AGC, BLC, HLC, DWDR


  Smart IR




🎤 Audio

•
  Microphone: Built-in

•
  Audio Transmission: Over coaxial cable

•
  Pickup Range: ~5 meters


⚙️ Interface

•
  Video Output Port: 1 × BNC (4-in-1 switchable)


🏗️ General

•
  Material: Plastic

•
  Dimensions: 138.8 × 70 mm

•
  Weight: ~160 g

•
  Operating Temperature: -40°C to +60°C

•
  Humidity: ≤90%


🔌 Power

•
  Supply: 12V DC ±25%

•
  Power Consumption: Max 2.9W


🛡️ Protection

•
  Weather Rating: IP67 (dust & water resistant)


🔄 Adjustments

•
  Pan: 0° – 360°

•
  Tilt: 0° – 90°

•
  Rotation: 0° – 360°


✅ Key Highlights

•
  3K resolution (better than 1080p)

•
  Built-in mic (audio over coax)

•
  Dual-light (IR + color night vision)

•
  Works with almost all analog DVR formats

•
  Suitable for harsh outdoor environments
