📷 Camera

•
  Image sensor: 1/3" Progressive Scan CMOS

•
  Max resolution: 2688 × 1520 (4 MP)

•
  Minimum illumination:


  Color: 0.005 Lux @ F1.6


  0 Lux with light (IR/white light)



•
  Shutter speed: 1/3 s to 1/100,000 s

•
  Day/Night: IR cut filter


🔍 Lens

•
  Type: Fixed lens

•
  Options: 2.8 mm / 4 mm / 6 mm

•
  Aperture: F1.6

•
  Field of View (approx.):


  2.8 mm: 104° horizontal


  4 mm: 84° horizontal


  6 mm: 52° horizontal




🌙 Illuminator (Night Vision)

•
  Type: Smart Hybrid Light (IR + White Light)

•
  Range: Up to 40 m

•
  IR wavelength: 850 nm


🎥 Video

•
  Frame rate:


  25 fps (50 Hz) / 30 fps (60 Hz)



•
  Compression:


  H.265 / H.265+ / H.264 / H.264+



•
  Bitrate: 32 Kbps – 8 Mbps

•
  WDR: 120 dB True WDR


🎤 Audio

•
  Built-in microphone (-2U version: dual mic)

•
  Compression: G.711, G.722.1, G.726, MP3, AAC-LC


🌐 Network

•
  Ethernet: 1 × RJ45 (10/100 Mbps)

•
  Storage:


  microSD card support up to 512 GB




🧠 Smart Features (AcuSense)

•
  Human & vehicle detection

•
  Line crossing detection

•
  Intrusion detection

•
  Face detection


🔔 Events

•
  Motion detection (human/vehicle filtering)

•
  Video tampering alarm

•
  Email alerts, FTP/NAS upload, recording trigger


🔌 Power

•
  12V DC ±25% (max 6 W)

•
  PoE (IEEE 802.3af, max 7.5 W)


🧱 Physical & Environmental

•
  Material: Metal housing

•
  Protection: IP67 (waterproof & dustproof)

•
  Operating temperature: -30°C to 60°C

•
  Dimensions: Ø74.4 × 176.3 mm

•
  Weight: ≈ 515 g


⚙️ Additional Features

•
  3D DNR (noise reduction)

•
  BLC / HLC (backlight compensation)

•
  ROI (Region of Interest)

•
  Privacy masking (up to 8 areas)


✔️ Summary

•
  Resolution: 4MP

•
  Night vision: Hybrid IR + white light (40 m)

•
  AI: Human/vehicle detection

•
  Storage: Up to 512GB SD

•
  Durability: IP67 outdoor
