📷 Camera

•
  Image Sensor: 1/3" Progressive Scan CMOS

•
  Max Resolution: 2560 × 1440 (4MP)

•
  Min. Illumination:


  Color: 0.005 Lux @ F1.6


  B/W: 0 Lux (IR on)



•
  Shutter Speed: 1/3 s to 1/100,000 s

•
  Day/Night: IR cut filter

•
  Angle Adjustment:


  Pan: 0°–355°


  Tilt: 0°–75°


  Rotate: 0°–355°




🔍 Lens

•
  Lens Type: Fixed focal

•
  Focal Length: 2.8 mm

•
  Field of View:


  Horizontal: 98°


  Vertical: 54°


  Diagonal: 114°



•
  Aperture: F1.6

•
  Lens Mount: M12


🌙 Illumination

•
  Light Type: IR + White Light (Smart Hybrid Light)

•
  Range: Up to 30 m

•
  IR Wavelength: 850 nm


🎥 Video

•
  Main Stream:


  4MP: up to 20 fps


  1080p/720p: up to 25 fps



•
  Sub Stream: up to 25 fps @ 720p

•
  Compression: H.265+/H.265/H.264+/H.264

•
  Bit Rate: 32 Kbps – 8 Mbps

•
  Bitrate Control: CBR / VBR


🔊 Audio

•
  Built-in Mic: Yes

•
  Audio Type: Mono

•
  Compression: G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC

•
  Sampling Rate: 8 kHz / 16 kHz


🧠 Smart Features

•
  Human & vehicle detection

•
  Motion detection (smart analytics)

•
  ROI (Region of Interest)

•
  Noise filtering


🌐 Network

•
  Protocols: TCP/IP, HTTP, RTSP, FTP, DHCP, DNS, NTP, IPv6, etc.

•
  ONVIF Support: Yes (Profile S/T/G depending on version)

•
  Simultaneous View: Up to 6 channels


💾 Storage

•
  MicroSD Card: Up to 512 GB (optional)


⚡ Power

•
  Power Supply: PoE (IEEE 802.3af)

•
  Power Consumption: Max. ~7.5 W


🛡️ Protection & Build

•
  Weatherproof: IP67

•
  Vandal Resistant: IK08

•
  Material: Metal + Plastic


🌡️ Environment

•
  Operating Temperature: -30°C to 60°C

•
  Humidity: ≤95% (non-condensing)


📏 Physical

•
  Dimensions: Ø121.4 × 97.7 mm

•
  Weight: ~550 g


📌 DORI (2.8mm Lens)

•
  Detect: 63 m

•
  Observe: 25 m

•
  Recognize: 12 m

•
  Identify: 6 m
