General
Number of Ports
? DGS-1024C: Twenty-four 10/100/1000 Gigabit ports
Standards
? IEEE 802.3 10BASE-T Ethernet
? IEEE 802.3u 100BASE-TX Fast Ethernet
? IEEE 802.3ab 1000BASE-T Gigabit Ethernet
? ANSI/IEEE 802.3 NWay auto-negotiation
? IEEE 802.3x Flow Control
Data Transfer Rates
? Ethernet:
? 10 Mbps (half duplex)
? 20 Mbps (full duplex)
? Fast Ethernet:
? 100 Mbps (half duplex)
? 200 Mbps (full duplex)
? Gigabit Ethernet:
? 2000 Mbps (full duplex)
Network Cables
? 10BASE-T:
? UTP CAT 3, 4, 5/5e (100 m max)
? EIA/TIA-586 100-ohm STP (100 m max)
? 100BASE-TX, 1000BASE-T:
? UTP CAT 5/5e (100 m max)
? EIA/TIA-568 100-ohm STP (100 m max)
Functionality
D-Link Green Features
? Power saving by link status and cable length
Security
? Storm Control
QoS (Quality of Service)
? 802.1p priority
? 8 queues
Cable Diagnostics
? Indicated through port LEDs
Switching Features
Protocol
? CSMA/CD
Switching Capacity
? DGS-1016D: 32 Gbps
? DGS-1024D: 48 Gbps
Max Forwarding Rate
? DGS-1024D: 35.71 mpps
Packet Buffer RAM
? 512 KBytes per device
Filtering Address Table:
? 8K MAC addresses per device
Packet Filtering/Forwarding Rate
? Ethernet: 14,880 pps per port
? Fast Ethernet: 148,800 pps per port
? Gigabit Ethernet: 1,488,000 pps per port
MAC Address Learning
? Self-learning, auto-aging
Forwarding Mode
? Store-and-forward
Physical & Environmental
Indicator LEDs
? Power LED (per device)
? Link/Activity/Speed LEDs (per port)
DIP Switch
? Energy-Efficient Ethernet (EEE)
? Flow Control
? Port Isolation and Storm Control
AC Input
? DGS-1024D:
? Internal universal power supply
? 100~240 V AC; 50 to 60 Hz, 0.3 A max
Maximum Power Consumption
? DGS-1024D: 13.3 W
Standby Power Consumption
? DGS-1024D: 4.4 W
Maximum Heat Dissipation:
? DGS-1024D: 45.35 BTU/h
MTBF
?? DGS-1024D: 863,100 hours
Acoustic Value:
? 0 dB(A) Fanless
Dimensions
? DGS-1024D: 280 x 180 x 44 mm (11.02 x 7.09 x 1.73 inch)
Weight
? DGS-1024D: 1.30 kg (2.87 lbs)
Operating Temperature:
? 0 ?C to 40 ?C (32 ?F to 104 ?F)
Storage Temperature:
? -10 ?C to 70 ?C (14 ?F to 158 ?F)
Operating Humidity:
? 0% to 95% RH, non-condensing
Storage Humidity
? 0% to 95% RH
Certifications
Emission Certifications (EMI)
? ICES-003 Class A
? FCC Class A
? RCM Class A
? BSMI Class A
? CE Class A
? VCCI A
? CCC
? KCC
Safety
? cUL/UL
? CE LVD
? CCC
? CB
? BSMI
Ordering Information
? DGS-1024D 24-Port Unmanaged Gigabit Switch
