📷 Camera

•
  Image Sensor: 3K CMOS

•
  Max Resolution: 2960 × 1665

•
  Min. Illumination:


  0.01 Lux (F2.0, AGC ON)


  0 Lux with IR



•
  Shutter Speed:


  PAL: 1/25 s to 1/50,000 s


  NTSC: 1/30 s to 1/50,000 s



•
  Day/Night Mode: ICR (Auto)

•
  Angle Adjustment:


  Pan: 0°–360°


  Tilt: 0°–75°


  Rotation: 0°–360°



•
  Signal System: PAL / NTSC


🔍 Lens (2.8mm version)

•
  Lens Type: Fixed focal

•
  Focal Length: 2.8 mm

•
  Field of View:


  Horizontal: ~105°


  Vertical: ~62°


  Diagonal: ~132°



•
  Lens Mount: M12


🎤 Audio

•
  Microphone: Built-in

•
  Audio Transmission: Audio over coaxial cable

•
  Pickup Range: Up to 5 meters


🌙 Illuminator (Night Vision)

•
  Light Type: Smart Hybrid Light (IR + White Light)

•
  IR Distance: Up to 20 m

•
  White Light Distance: Up to 20 m


🎥 Video & Image

•
  Frame Rate:


  3K @ 20fps


  4MP @ 25/30fps


  1080p @ 25/30fps



•
  Video Output: Switchable


  TVI / AHD / CVI / CVBS



•
  WDR: Digital WDR

•
  Image Features:


  DWDR, BLC, HLC


  Smart IR


  Brightness & Sharpness adjustment



•
  White Balance: Auto / Manual

•
  AGC: Yes


🔌 Interface

•
  Video Output: 1 analog HD output (4-in-1 switchable)


⚙️ General

•
  Material: Plastic

•
  Dimensions: 84.6 mm × 85 mm

•
  Weight: ~160 g

•
  Operating Temperature: -40°C to +60°C

•
  Humidity: ≤90% (non-condensing)

•
  Power Supply: 12V DC ±25%

•
  Power Consumption: Max. 2.9W


✔️ Key Highlights

•
  3K high-resolution video

•
  Built-in mic (audio recording)

•
  Smart hybrid night vision (color + IR)

•
  Wide-angle 2.8mm lens

•
  Compatible with most DVRs (TVI/AHD/CVI/CVBS)
