📷 Image & Video

•
  Image Sensor: 1/3" Progressive Scan CMOS

•
  Max Resolution: 4 MP (2688 × 1520)

•
  Frame Rate: Up to 30 fps

•
  Minimum Illumination:


  Color: 0.005 Lux @ (F1.6, AGC ON)


  B/W: 0 Lux with IR



•
  Shutter Speed: 1/3 s to 1/100,000 s

•
  Day/Night: IR cut filter with auto switch


🌙 Lens & Field of View

•
  Lens Options: Fixed lens (2.8 mm / 4 mm / 6 mm)

•
  Aperture: F1.6

•
  Field of View (approx.):


  2.8 mm: ~103° horizontal


  4 mm: ~83° horizontal


  6 mm: ~55° horizontal




🌑 Infrared & Low-Light

•
  IR Range: Up to 30 m

•
  Smart IR: Yes (adjusts intensity to avoid overexposure)


🎥 Video Compression

•
  Main Stream: H.265+, H.265, H.264+, H.264

•
  Sub-stream: H.265, H.264, MJPEG

•
  Bitrate Control: CBR / VBR


🧠 Intelligent Features

•
  Motion Detection

•
  Line Crossing Detection

•
  Intrusion Detection

•
  Video Tampering Alarm

•
  Exception Detection (network/storage issues)


🌗 Image Enhancement

•
  WDR: 120 dB True WDR

•
  3D DNR: Yes (noise reduction)

•
  BLC / HLC: Yes

•
  Image Settings: Brightness, contrast, saturation, sharpness adjustable


🌐 Network

•
  Ethernet: 1 RJ45 10M/100M self-adaptive

•
  Protocols: TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, etc.

•
  ONVIF: Supported (Profile S, G, T)

•
  Simultaneous Live View: Up to 6 channels


🔌 Interface

•
  Audio: Depends on model variant (some support built-in mic)

•
  Alarm I/O: Not available in base model

•
  Reset Button: Yes


⚡ Power

•
  Power Supply: 12 V DC ±25%

•
  PoE: IEEE 802.3af

•
  Power Consumption: Max ~6.5 W


🛡️ Build & Environment

•
  Protection Level: IP67 (waterproof & dustproof)

•
  Vandal Resistance: IK10

•
  Operating Temperature: -30°C to +60°C

•
  Material: Metal housing


📏 Physical

•
  Dimensions: Approx. Ø121 mm × 92 mm

•
  Weight: ~500–600 g


💾 Storage

•
  Local Storage: microSD/SDHC/SDXC (up to 256 GB)

•
  Network Storage: NAS, NVR support
