📊 Camera

•
  Image Sensor: 1/2.8" Progressive Scan CMOS

•
  Max Resolution: 3840 × 2160 (8 MP / 4K)

•
  Min. Illumination:


  Color: 0.005 Lux @ F1.6


  B/W: 0 Lux with IR



•
  Shutter Speed: 1/3 s to 1/100,000 s

•
  Day/Night: IR cut filter

•
  Adjustment: Pan 0–360°, Tilt 0–90°, Rotate 0–360°


🔍 Lens

•
  Type: Fixed lens

•
  Options: 2.8 mm / 4 mm / 6 mm

•
  Aperture: F1.6

•
  Mount: M12


Field of View (FOV)

•
  2.8 mm: H 108°, V 59°, D 127°

•
  4 mm: H 88°, V 44°, D 105°

•
  6 mm: H 54°, V 29°, D 63°


🌙 Illuminator

•
  Type: IR + White Light (Hybrid Light)

•
  Range: Up to 40 m

•
  IR Wavelength: 850 nm

•
  Smart Light: Yes


🎥 Video

•
  Main Stream:


  4K: up to 20 fps


  1080p: up to 25/30 fps



•
  Compression: H.265 / H.264 / H.265+ / H.264+

•
  Bitrate: 32 Kbps – 16 Mbps

•
  Streams: Triple stream support

•
  ROI & Target Cropping: Supported


🎤 Audio (-2U Version)

•
  Built-in: Dual-array microphone

•
  Compression: G.711 / G.722.1 / G.726 / MP2L2 / MP3 / AAC-LC

•
  Bitrate: 8–320 Kbps (depending on codec)


🧠 Smart Features (AcuSense)

•
  Human & vehicle classification

•
  Perimeter protection:


  Line crossing


  Intrusion detection


  Region entrance/exit



•
  Smart events:


  Face detection


  Object removal


  Unattended baggage




🌗 Image Enhancement

•
  WDR: 120 dB

•
  SNR: ≥ 52 dB

•
  Features: BLC, HLC, 3D DNR

•
  Privacy Mask: Up to 8 areas


🌐 Network & Storage

•
  Ethernet: 1 × RJ45 (10/100 Mbps)

•
  Storage: microSD up to 512 GB

•
  Protocols: FTP, NAS, email alerts, etc.


🔌 Interface

•
  Built-in mic (dual mic for -2U)

•
  Reset button

•
  Memory card slot


⚡ Power

•
  12 VDC ±25%

•
  PoE: IEEE 802.3af

•
  Consumption: Max ~6–7.5 W


🏗️ General

•
  Material: Metal

•
  Dimensions: Ø74.4 × 176.3 mm

•
  Weight: ~515 g

•
  Operating Temp: -30°C to 60°C

•
  Protection: IP67 (water & dust resistant)


📏 DORI Distance (Detection Range)

•
  2.8 mm: Detect 84 m

•
  4 mm: Detect 117 m

•
  6 mm: Detect 176 m
